19 / 104
17
CAMLOG
®
IMPLANTATSYSTEM
SURGERY SCREW-LINE
CAMLOG
®
SCREW-LINE IMPLANTS PROMOTE
®
PLUS
The Promote
®
surface has proven its worth as a reliable dental implant surface. Numerous scientific studies demonstrate this. To
provide the bone with a larger rough surface as an anchor, the Promote
®
plus area of CAMLOG
®
SCREW-LINE Implants Promote
®
plus was increased by an additional portion of 1.0 mm, right up to the bone-soft tissue margin compared to the Promote
®
surface. This extends the bone-implant contact surface of Promote
®
plus upward to the esthetically relevant coronal zone. Since
they have the same insertion protocol, Promote
®
and Promote
®
plus implants can be used freely in combination.
Note: With CAMLOG
®
SCREW-LINE Implants with diameter 3.8/4.3/5.0/6.0 mm the option of Platform Switching
is possible. See also information on page 6.
Art. No.
Article
Ø
in mm
Length
in mm
Material
K1052.3311
K1052.3313
K1052.3316
CAMLOG
®
SCREW-LINE
Implant, Promote
®
plus
incl. insertion post
and cover screw, sterile
3.3
11
13
16
Titanium Grade 4
K1052.3809
K1052.3811
K1052.3813
K1052.3816
3.8
9
11
13
16
K1052.4309
K1052.4311
K1052.4313
K1052.4316
4.3
9
11
13
16
K1052.5009
K1052.5011
K1052.5013
K1052.5016
5.0
9
11
13
16
K1052.6009
K1052.6011
K1052.6013
K1052.6016
6.0
9
11
13
16
