CAMLOG
®
IMPLANTATSYSTEM
SURGERY SCREW-LINE
GUIDE SYSTEM
TEMPLATE-GUIDED IMPLANT BED PREPARATION AND IMPLANTATION
Note: All Guide System drills and gingiva punches are intended for single use only!
Art. No.
Article
Ø
in mm
Length
in mm
Material
Guide System Implants
K1053.3311
K1053.3313
K1053.3316
Guide System CAMLOG
®
SCREW-LINE
Implant, Promote
®
plus,
incl. Guide System CAMLOG
®
Insertion post and CAMLOG
®
Cover screw
3.3
3.3
3.3
11
13
16
Titanium Grade 4
K1053.3809
K1053.3811
K1053.3813
K1053.3816
3.8
3.8
3.8
3.8
9
11
13
16
K1053.4309
K1053.4311
K1053.4313
K1053.4316
4.3
4.3
4.3
4.3
9
11
13
16
Guide System Pilotbohrer
J5043.3311
Guide System Pilot drill set, for
Ø
3.3 mm,
internal irrigation, sterile,
Content: Guide System pilot drills
Ø
2.0 mm, length 5, 9 and 11 mm
3.3
11 Stainless steel
J5043.3313
Guide System Pilot drill set, for
Ø
3.3 mm,
internal irrigation, sterile,
Content: Guide System pilot drills
Ø
2.0 mm, length 5, 9, 11 and 13 mm
3.3
13
J5044.3316
Guide System Pilot drill, for
Ø
3.3 mm,
internal irrigation, sterile,
Ø
2.0 mm, length 16 mm
3.3
16
J5043.4309
Guide System Pilot drill set, for
Ø
3.8/4.3 mm,
internal irrigation, sterile,
Content: Guide System pilot drills
Ø
2.0 mm, length 5 and 9 mm
3.8
9 Stainless steel
4.3
J5043.4311
Guide System Pilot drill set, for
Ø
3.8/4.3 mm,
internal irrigation, sterile,
Content: Guide System pilot drills
Ø
2.0 mm, length 5, 9 and 11 mm
3.8
11
4.3
J5043.4313
Guide System Pilot drill set, for
Ø
3.8/4.3 mm,
internal irrigation, sterile,
Content: Guide System pilot drills
Ø
2.0 mm, length 5, 9, 11 and 13 mm
3.8
13
4.3
J5044.4316
Guide System Pilot drill, for
Ø
3.8/4.3 mm,
internal irrigation, sterile,
Ø
2.0 mm, length 16 mm
3.8
16
4.3
