CAMLOG
®
IMPLANTATSYSTEM
CAMLOG
®
PROSTHETICS
HYBRID RESTORATIONS
DOUBLE CROWN RESTORATIONS WITH CAMLOG
®
UNIVERSAL AND TELESCOPE ABUTMENTS
CAMLOG
®
Universal abutments PS for double crown restorations, for Platform Switching,
preparable, incl. CAMLOG
®
Abutment screw
K2201.3800
PS
3.8
–
Titanium alloy
K2201.4300
4.3
–
K2201.5000
5.0
–
K2201.6000
6.0
–
Note: CAMLOG
®
Universal abutments PS should only be used on CAMLOG
®
Implants with K article number!
CAMLOG
®
Telescope abutments for double crown restorations,
preparable, incl. CAMLOG
®
Abutment screw
K2212.3800
3.8
–
Titanium alloy
K2212.4300
4.3
–
K2212.5000
5.0
–
K2212.6000
6.0
–
Art. No.
Article
Ø
in mm
Dimension
in mm
Material
CAMLOG
®
Universal abutments for double crown restorations,
preparable, incl. CAMLOG
®
Abutment screw
K2211.3800
3.8
–
Titanium alloy
K2211.4300
4.3
–
K2211.5000
5.0
–
K2211.6000
6.0
–
H 11
H 11
H 12
ACCESSORIES FOR CAMLOG
®
ABUTMENTS
Abutment screws for the definitive screwing of abutments into the implant
J4005.1601
CAMLOG
®
Abutment screw,
hex
3.3
Thread
M 1.6
Titanium alloy
3.8
4.3
J4005.2001
5.0 Thread
M 2.0
6.0
Laborschrauben für die Befestigung auf dem Arbeitsmodell
J4006.1601
CAMLOG
®
Lab screw, hex,
brown anodized
3.3
Thread
M 1.6
Titanium alloy
3.8
4.3
J4006.2001
5.0 Thread
M 2.0
6.0
Note: Lab screws be used on working models only.
H: height in mm
