CAMLOG® IMPLANTATSYSTEM
Guide System Form drill, SCREW-LINE
J5046.3316 Ø 3.3 mm, L 16 mm................................................ 27
J5046.3816 Ø 3.8 mm, L 16 mm................................................ 27
J5046.4316 Ø 4.3 mm, L 16 mm................................................ 27
Guide System Form drill, Cortical bone
J5048.3311 Ø 3.3 mm, L 11 mm................................................ 28
J5048.3313 Ø 3.3 mm, L 13 mm................................................ 28
J5048.3316 Ø 3.3 mm, L 16 mm................................................ 28
J5048.3809 Ø 3.8 mm, L 9 mm................................................ 28
J5048.3811 Ø 3.8 mm, L 11 mm................................................ 28
J5048.3813 Ø 3.8 mm, L 13 mm................................................ 28
J5048.3816 Ø 3.8 mm, L 16 mm................................................ 28
J5048.4309 Ø 4.3 mm, L 9 mm................................................ 28
J5048.4311 Ø 4.3 mm, L 11 mm................................................ 28
J5048.4313 Ø 4.3 mm, L 13 mm................................................ 28
J5048.4316 Ø 4.3 mm, L 16 mm................................................ 28
Round bur
J5050.2300 Ø 2.3 mm........................................................ 19, 32
J5050.3500 Ø 3.5 mm........................................................ 19, 32
Pilot drill SCREW-LINE,
reduced coil
J5051.2000 Ø 2.0 mm........................................................ 19, 32
Pilot drill without coil
J5051.2003 Ø 2.0 mm........................................................ 19, 32
Pre-drill SCREW-LINE
J5051.2800 Ø 1.7-2.8 mm.................................................. 19, 32
Form drill SCREW-LINE,
reduced coil
J5052.3309 Ø 3.3 mm, L 9 mm................................................ 20
J5052.3311 Ø 3.3 mm, L 11 mm................................................ 20
J5052.3313 Ø 3.3 mm, L 13 mm................................................ 20
J5052.3316 Ø 3.3 mm, L 16 mm................................................ 20
J5052.3809 Ø 3.8 mm, L 9 mm................................................ 20
J5052.3811 Ø 3.8 mm, L 11 mm................................................ 20
J5052.3813 Ø 3.8 mm, L 13 mm................................................ 20
J5052.3816 Ø 3.8 mm, L 16 mm................................................ 20
J5052.4309 Ø 4.3 mm, L 9 mm................................................ 20
J5052.4311 Ø 4.3 mm, L 11 mm................................................ 20
J5052.4313 Ø 4.3 mm, L 13 mm................................................ 20
J5052.4316 Ø 4.3 mm, L 16 mm................................................ 20
J5052.5009 Ø 5.0 mm, L 9 mm................................................ 20
J5052.5011 Ø 5.0 mm, L 11 mm................................................ 20
J5052.5013 Ø 5.0 mm, L 13 mm................................................ 20
J5052.5016 Ø 5.0 mm, L 16 mm................................................ 20
J5052.6009 Ø 6.0 mm, L 9 mm................................................ 20
J5052.6011 Ø 6.0 mm, L 11 mm................................................ 20
J5052.6013 Ø 6.0 mm, L 13 mm................................................ 20
J5052.6016 Ø 6.0 mm, L 16 mm................................................ 20
Form drill SCREW-LINE, Cortical bone
J5053.3316 Ø3.3 mm............................................................... 21
J5053.3816 Ø3.8 mm............................................................... 21
J5053.4316 Ø4.3 mm............................................................... 21
J5053.5016 Ø5.0 mm............................................................... 21
J5053.6016 Ø6.0 mm............................................................... 21
Tap SCREW-LINE, with hexagon
J5054.3309 Ø 3.3 mm............................................................... 21
J5054.3809 Ø 3.8 mm............................................................... 21
J5054.4309 Ø 4.3 mm............................................................... 21
J5054.5009 Ø 5.0 mm............................................................... 21
J5054.6009 Ø 6.0 mm............................................................... 21
Form drill ROOT-LINE 2, with reduced coil
J5055.3309 Ø 3.3 mm, L 9 mm................................................ 33
J5055.3311 Ø 3.3 mm, L 11 mm................................................ 33
J5055.3313 Ø 3.3 mm, L 13 mm................................................ 33
J5055.3316 Ø 3.3 mm, L 16 mm................................................ 33
J5055.3809 Ø 3.8 mm, L 9 mm................................................ 33
J5055.3811 Ø 3.8 mm, L 11 mm................................................ 33
J5055.3813 Ø 3.8 mm, L 13 mm................................................ 33
J5055.3816 Ø 3.8 mm, L 16 mm................................................ 33
J5055.4309 Ø 4.3 mm, L 9 mm................................................ 33
J5055.4311 Ø 4.3 mm, L 11 mm................................................ 33
J5055.4313 Ø 4.3 mm, L 13 mm................................................ 33
J5055.4316 Ø 4.3 mm, L 16 mm................................................ 33
J5055.5009 Ø 5.0 mm, L 9 mm................................................ 33
J5055.5011 Ø 5.0 mm, L 11 mm................................................ 33
J5055.5013 Ø 5.0 mm, L 13 mm................................................ 33
J5055.5016 Ø 5.0 mm, L 16 mm................................................ 33
J5055.6009 Ø 6.0 mm, L 9 mm................................................ 33
J5055.6011 Ø 6.0 mm, L 11 mm................................................ 33
J5055.6013 Ø 6.0 mm, L 13 mm................................................ 33
J5055.6016 Ø 6.0 mm, L 16 mm................................................ 33
Tap ROOT-LINE 2, with hexagon
J5056.3309 Ø 3.3 mm............................................................... 33
J5056.3809 Ø 3.8 mm............................................................... 33
J5056.4309 Ø 4.3 mm............................................................... 33
J5056.5009 Ø 5.0 mm............................................................... 33
J5056.6009 Ø 6.0 mm............................................................... 33
Driver for screw implants,
with ISO shaft for angled hand piece
J5300.0007 L 27.5 mm. ............................................................. 36
Driver, short, for screw implants,
manual/wrench
J5300.0008 L 18.0 mm. ............................................................. 36
Driver, long, for screw implants,
manual/wrench
J5300.0009 L 27.0 mm. ............................................................. 36
J5300.0010 Cardanic driver (30°)............................................ 37
Driver for ball abutment,
manual/wrench
J5300.0011 L 18.3 mm. ............................................................. 39
Driver for bar abutment
J5300.0020 Ø 3.3/3.8/4.3 mm, L 18.6 mm................................. 39
J5300.0025 Ø 5.0/6.0 mm, L 18.6 mm....................................... 39
Driver for impression post and healing cap
for bar abutment
J5300.0027 Ø3.3/3.8/4.3 mm, L 19.1 mm................................. 39
J5300.0028 Ø5.0/6.0 mm, L 19.1 mm....................................... 39
PickUp instrument
J5300.0030 holder for carrying implants...................................... 37
J5300.0057 Surgery set CAMLOG ®/CONELOG® SCREW-LINE... 18
J5300.0059 Surgery set CAMLOG® ROOT-LINE 2.................... 31
Paralleling pin SCREW-LINE
J5300.2028 Ø1.7-2.8/2.0 mm................................................... 36
J5300.8915 Surgery tray CAMLOG®ROOT-LINE 2 (without content) 31
Guide System Check-up pin
J5301.3300 Ø 3.3 mm............................................................... 29
J5301.4300 Ø 3.8/4.3 mm......................................................... 29
J5302.0010 Holding key for insertion post............................ 37
Holding sleeve for screw implants, color-coded
J5302.3300 Ø 3.3 mm............................................................... 37
J5302.3800 Ø 3.8 mm............................................................... 37
J5302.4300 Ø 4.3 mm............................................................... 37
INDEX
ARTICLE NUMBERS
Article No. Article Page Article No. Article Page
