CAMLOG® IMPLANTATSYSTEM
CAMLOG® PROSTHETICS
CROWN, BRIDGE AND HYBRID RESTORATIONS
CAD/CAM PROSTHETICS
CAMLOG® Lab screws, hex, for the fixation of abutments on the working model, brown anodized
J4006.1601
3.3
Thread
M 1.6
Titanium alloy
3.8
4.3
J4006.2001
5.0 Thread
M 2.0 6.0
Note: Lab screws be used on working models only.
Art. No. Article Ø
in mm
Dimension
in mm
Material
CAMLOG® Scanbodies, for optical, 3-dimensional localization of CAMLOG® Implants in the mouth or CAMLOG®
Lab analogs in the working model, incl. CAMLOG® Abutment screw, sterile
K2610.3310 3.3 – PEEK
K2610.3810* 3.8 –
K2610.4310* 4.3 –
K2610.6010* 5.0
–
6.0
*also for Platform Switching
ACCESSORIES FOR CAMLOG® ABUTMENTS
CAMLOG® Bonding aids, for securing CAMLOG® Abutments and CAMLOG® Titanium bases CAD/CAM on the
working model and for protecting the screw channel, white (2 units)
J4009.1600 3.3
Thread
M 1.6
POM
3.8
4.3
J4009.2000 5.0 Thread
M 2.0
6.0
CAMLOG® Abutment screws, hex, for definitive screw retention of abutments into the implant
J4005.1601
3.3
Thread
M 1.6
Titanium alloy
3.8
4.3
J4005.2001
5.0 Thread
M 2.0 6.0
Note: Some scan systems require the use of system-intrinsic scan abutments.
For information on the compatibility of the CAMLOG® Scanbody with suitable dental CAD systems see
Technology.
POM: Polyoxymethylene
PEEK: Poly ether ether ketone
H: height in mm
H 10
CAMLOG® ScanPosts for Sirona Scanbody, for digital recording of the CAMLOG ® Implant or lab analog position,
incl. CAMLOG® Abutment screw
K2620.3306 3.3 – Titanium alloy
K2620.3806 3.8 –
K2620.4306 4.3 –
K2620.5006 5.0 –
K2620.6006 6.0 –
H 10.2
