CAMLOG
®
IMPLANTATSYSTEM
CAMLOG
®
PROSTHETICS
CROWN AND BRIDGE RESTORATIONS
CAMLOG
®
UNIVERSAL ABUTMENTS FOR CEMENTED CROWN AND BRIDGE RESTORATIONS
Art. No.
Article
Ø
in mm
Dimension
in mm
Material
CAMLOG
®
Universal abutments,
preparable, incl. CAMLOG
®
Abutment screw
K2211.3300
3.3*
–
Titanium alloy
K2211.3800
3.8
–
K2211.4300
4.3
–
K2211.5000
5.0
–
K2211.6000
6.0
–
CAMLOG
®
Universal abutments PS for Platform Switching,
preparable, incl. CAMLOG
®
Abutment screw
K2201.3800
PS
3.8
–
Titanium alloy
K2201.4300
4.3
–
K2201.5000
5.0
–
K2201.6000
6.0
–
Note: CAMLOG
®
Universal abutments PS should only be used on CAMLOG
®
Implants with K article number!
* only for crown restorations in the region of the upper lateral and lower lateral and central incisors (
Ø
3.3 mm not for double crown restorations)
H 11
H 11
CAMLOG
®
GOLD-PLASTIC ABUTMENTS FOR CEMENTED CROWN AND BRIDGE RESTORATIONS
CAMLOG
®
Gold-plastic abutments,
cast-on, incl. CAMLOG
®
Abutment screw
K2246.3300
3.3* 0,42 g**
Cast-on gold
alloy/POM
K2246.3800
3.8 0,46 g**
K2246.4300
4.3 0,65 g**
K2246.5000
5.0 0,81 g**
K2246.6000
6.0 0,89 g**
CAMLOG
®
CERAMIC ABUTMENTS FOR CROWN RESTORATIONS
CAMLOG
®
Ceramic abutments, 2-parts, for bonded/cemented full ceramic crowns
preparable, incl. CAMLOG
®
Titanium base, zirkonium oxide sleeve and CAMLOG
®
Abutment screw
K2242.3340
3.3*
–
Titanium alloy/
Zirkonium oxide
K2242.3840
3.8
–
K2242.4340
4.3
–
K2242.5040
5.0
–
K2242.6040
6.0
–
H: height in mm
** Noble metal weight approx.
H 11.7
