CAMLOG
®
IMPLANTATSYSTEM
CAMLOG
®
PROSTHETICS
CROWN AND BRIDGE RESTORATIONS
TEMPORARY RESTORATION
Art. No.
Article
Ø
in mm
GH
in mm
Material
PEEK: Poly ether ether ketone
H: height in mm
CAMLOG
®
Temporary abutments (PEEK)
preparable, incl. CAMLOG
®
Abutment screw
K2241.3800
3.8
–
PEEK
K2241.4300
4.3
–
K2241.5000
5.0
–
K2241.6000
6.0
–
CAMLOG
®
Temporary abutments PS (PEEK), for Platform Switching,
preparable, incl. CAMLOG
®
Abutment screw
K2208.3800
PS
3.8
–
PEEK
K2208.4300
4.3
–
K2208.5000
5.0
–
K2208.6000
6.0
–
Note: CAMLOG
®
Temporary abutments PS should only be used on CAMLOG
®
Implants with K article number!
CAMLOG
®
ESTHOMIC
®
ABUTMENTS FOR CEMENTED CROWN AND BRIDGE RESTORATIONS
CAMLOG
®
Esthomic
®
Abutments, straight,
preparable, incl. CAMLOG
®
Abutment screw
K2226.3810
K2226.3830
H 9
H 11.7
3.8
1.0-1.8
3.0-4.5
Titanium alloy
K2226.4310
K2226.4330
4.3
1.0-1.8
3.0-4.5
K2226.5010
K2226.5030
5.0
1.0-1.8
3.0-4.5
K2226.6010
K2226.6030
6.0
1.0-1.8
3.0-4.5
GH: gingiva height
H 12
H 12
CAMLOG
®
Esthomic
®
Abutments, 15° angled, type A,
preparable, incl. CAMLOG
®
Abutment screw
K2227.3810
K2227.3830
H 9
H 11.7
3.8
1.0-1.8
3.0-4.5
Titanium alloy
K2227.4310
K2227.4330
4.3
1.0-1.8
3.0-4.5
K2227.5010
K2227.5030
5.0
1.0-1.8
3.0-4.5
K2227.6010
K2227.6030
6.0
1.0-1.8
3.0-4.5
