52 / 104
50
CAMLOG
®
IMPLANTATSYSTEM
CAMLOG
®
PROSTHETICS
IMPRESSION TAKING, BITE REGISTRATION, FABRICATION OF THE PLASTER MODEL
IMPRESSION TAKING
Art. No.
Article
Ø
in mm
Dimension
in mm
Material
CAMLOG
®
Impression posts, open tray,
incl. fixing screw
(The fixing screw can be shortened extra-oral by 3 mm with a screwdriver, hex.)
K2121.3300
3.3 21.0/24.0 Titanium alloy
K2121.3800
3.8 21.0/24.0
K2121.4300
4.3 21.0/24.0
K2121.5000
5.0 21.0/24.0
K2121.6000
6.0 21.0/24.0
CAMLOG
®
Impression posts, closed tray,
incl. impression cap, bite registration cap and fixing screw
K2110.3300
3.3
–
Titanium alloy
K2110.3800
3.8
–
K2110.4300
4.3
–
K2110.5000
5.0
–
K2110.6000
6.0
–
H 10.7
H 10
CAMLOG
®
Impression posts PS, closed tray, for Platform Switching,
incl. impression cap, bite registration cap and fixing screw
K2109.3800
PS
3.8
–
Titanium alloy
K2109.4300
4.3
–
K2109.5000
5.0
–
K2109.6000
6.0
–
Note: CAMLOG
®
Impression posts PS should only be used for impression taking of CAMLOG
®
Implants with
K article number!
H: height in mm
CAMLOG
®
Impression posts PS, open tray, for Platform Switching,
incl. fixing screw
(The fixing screw can be shortened extra-oral by 3 mm with a screwdriver, hex)
K2119.3800
PS
3.8 21.0/24.0 Titanium alloy
K2119.4300
4.3 21.0/24.0
K2119.5000
5.0 21.0/24.0
K2119.6000
6.0 21.0/24.0
H 10
H 3
H 3
H 10.7
