80 / 104
78
CAMLOG
®
IMPLANTATSYSTEM
INFORMATION
MATERIALS
Titanium Grade 4
Properties (ASTM F67):
Chemical structure (in %):
O
≤
0.4
Fe
≤
0.5
C
≤
0.08
N
≤
0.05
H
≤
0.015
Ti
Rest
Mechanical properties:
Tensile strength
≥
550 MPa
Elongation at break
≥
15 %
Cast-on gold alloy
CAMLOG
®
Gold-plastic
abutment
Properties:
Chemical structure (in %):
Au
60
Pd
20
Pt
19
Ir
1
Physical properties:
Melting range
1400 - 1490 °C
Density
17.5 g/cm
3
E-Modul
136 GPa
Coefficient of thermal
expansion (25-500°C)
11.9 µm/m·°C
Coefficient of thermal
expansion (25-600°C)
12.2 µm/m·°C
Color
white
Mechanical properties:
drawn
Hardness HV5
> 215
Tensile strength (Rm)
> 750 MPa
0.2% Elongation limit
(Rp 0.2%)
> 650 MPa
Elongation at break
> 2%
Properties (ASTM F136):
Chemical structure (in %):
AI
5.5 - 6.5
V
3.5 - 4.5
Fe
≤
0.25
C
≤
0.08
N
≤
0.05
O
≤
0.13
H
≤
0.012
Ti
Rest
Mechanical properties:
Tensile strength
≥
860 MPa
Elongation at break
≥
10 %
Titanium alloy Ti6AI4V ELI
