CAMLOG
®
IMPLANTATSYSTEM
INFORMATION
MATERIALS
Solderable gold alloy
Base for bar abutment
Properties:
Chemical structure (in %):
Au
70.00
Pt
8.50
Ag
13.40
Pd
-
Cu
7.50
Zn
0.50
Ir
0.10
Rh
-
Ru
-
Mechanical properties:
Color
yellow
Melting range
895 - 1010 °C
Hardness
annealed HV5
170
hardened HV5
295
self hardened HV5
280
Zirconium oxide
Properties:
Chemical structure (in %):
ZrO
2
+ HfO
2
+ Y
2
O
3
> 99.0
Y
2
O
3
4.5 - 5.4
HfO
2
< 5
AI
2
O
3
< 0.5
other oxides
< 0.5
Mechanical properties:
Density
> 6.0 g/cm
3
Porosity, open
0.00 %
Microstructure:
Mean Linear intercept size
< 0.6 µm
3 pt. transversal strength
≥
800 MPa
Cast-on gold alloy
Base for bar abutment
Properties:
Chemical structure (in %):
Au
60
Pt
19
Pd
20
Ir
1
Mechanical properties:
Density
17.5 g/cm
3
Color
white
Liquidus
1490 °C
Solidus
1400 °C
Coefficient of thermal
expansion (25-500°C)
12.5 µm/m·°C
Coefficient of thermal
expansion (25-600°C)
12.6 µm/m·°C
E-Modul
136.000 GPa
hardened
700 °C / 30 min.
Hardness HV5
210
0.2 % Elongation limit
450-570 MPa
Elongation at break
min 10 %
Tensile strength MPa
530-650
