THE CAMLOG
®
IMPLANT SYSTEM
SYSTEM INFORMATION
CAMLOG
®
IMPLANTATSYSTEM
THE CAMLOG
®
IMPLANT SYSTEM
The CAMLOG
®
Implant System is based on years of clinical
and laboratory experience and is a user-friendly, consistent
prosthetically oriented implant system.
The CAMLOG
®
Implant System is being continuously deve-
loped and adapted to the state of technology by the internal
research and development team in collaboration with clinics,
universities and dental technicians.
The CAMLOG
®
Implant System is well documented scien-
tifically. Numerous studies based on various parameters, e. g.
implant surface, time of implantation and/or implant loading,
primary stability, connection design or type of suprastructure,
support this. The long-term outcomes for the CAMLOG
®
Implant System are persuasive.
NEW PRODUCTS
CAMLOG
®
ROOT-LINE 2
CAMLOG
®
ROOT-LINE 2 Implants
The CAMLOG
®
ROOT-LINE Implants have been adapted and
are now available with the proven Tube-in-Tube™ implant-
abutment connection with short angular grooves, identical
to the inner configuration of the CAMLOG
®
SCREW-LINE
Implants. CAMLOG
®
ROOT-LINE 2 Implants are thus suitable
for the Platform Switching option (not for
Ø
3.3 mm).
In terms of outer geometry, the machined neck area was
shortened to 0.4 mm (Promote
®
plus). The thus enlarged
Promote
®
surface offers greater bone contact. The raised
cutting groove delivers optimized tightening, even in hard
bone.
The implant line was extended by the 3.3 mm diameter with
implant lengths of 11, 13 and 16 mm.
CAMLOG
®
ROOT-LINE 2 Instruments
The adaptation of the outer geometry of the CAMLOG
®
ROOT-
LINE Implants required new color-coded reusable form drills,
including depth stops and reusable taps, new without internal
irrigation.
LOCATOR
®
A new replacement male is available for the Locator
®
Anchoring system for extended range without retention. The
replacement male is colored gray and serves to adapt the
cumulated retention force of a Locator
®
retained prosthesis
on implants with diameters 3.8/4.3/5.0 mm.
GUIDE SYSTEM
The CAMLOG
®
Guide System for template-guided implant
bed preparation and insertion has been extended by the
CONELOG
®
SCREW-LINE Implants and is now called the
Guide System.
Guide System CONELOG
®
SCREW-LlNE Implants are available
with a 3.3 mm diameter in the lengths 9, 11, 13 and 16 mm,
as well as with 3.8 and 4.3 mm diameters in the lengths 7, 9,
11, 13 and 16 mm.
Additional Guide System CAMLOG
®
SCREW-LlNE Implants
were also added to the system. These are available new with
a diameter of 3.3 mm in the lengths 11, 13 and 16 mm, as
well as diameters 3.8 and 4.3 mm with a length of 16 mm,
including the corresponding surgical instruments.
Newly available are guided pilot drills and a driver with ISO
shaft for Guide System implants. The form drills were fitted
with a four-edged cutting geometry with chip grooves to
provide greater smoothness of operation. The guide sleeves
were shortened by 1 mm for minimally invasive implantation
at greater gingival thickness, provided with opposing bevels
for use in narrow tooth gaps and fitted with a marking to
give better groove alignment. The template drills are fitted
newly with a spiral-shaped cutting edge and a longer shaft.
All drills, gingiva punches, insertion posts and guide sleeves
are color-coded throughout.
The new Guide System comprises 85 items.
CAMLOG
®
ScanPost for Sirona Scanbody
In conjunction with a Sirona Scanbody, the new CAMLOG
®
ScanPost serves for the digital recording of the implant posi-
tion or laboratory analog position in relation to the remaining
teeth and the soft tissue.
