THE CAMLOG
®
IMPLANT SYSTEM
SYSTEM INFORMATION
CAMLOG
®
IMPLANTATSYSTEM
PLATFORM SWITCHING OPTION
CAMLOG
®
Healing caps PS for Platform
Switching
The CAMLOG
®
Healing caps PS (cylindrical, wide body, bottle-
neck) are tapered in diameter at the shoulder support making
it possible to adapt soft tissue over the implant shoulder.
CAMLOG
®
Impression posts PS, open and
closed tray for Platform Switching
Due to the adaptation of the soft tissue over the implant
shoulder, the use of the CAMLOG
®
Healing cap PS necessitates
the use of the CAMLOG
®
Impression post PS for Platform
Switching, with both having an identical geometry. The cams
of the impression posts are adapted to the grooves of the
CAMLOG
®
Implants.
CAMLOG
®
Temporary abutments PS,
CAMLOG
®
Esthomic
®
Abutments PS and
CAMLOG
®
Universal abutments PS for
Platform Switching
The CAMLOG
®
Abutments PS are also tapered in diameter in
the area of the shoulder support and thus allow adapting soft
tissue over the implant shoulder during prosthetic restorati-
on. The cams of the abutments are adapted to the grooves of
the CAMLOG
®
Implants.
The Platform Switching option is used to support the hard and
soft tissue in esthetic regions. Due to the horizontally reduced
diameter of the CAMLOG
®
Abutment PS in relationship to the
implant diameter, the implant-abutment interface on the im-
plant shoulder is shifted towards the middle of the implant.
The CAMLOG
®
Healing caps PS, impression posts PS and
abutments PS are for exclusive use only with CAMLOG
®
Implants with K article numbers.
PS: Platform Switching
